VO Series


Voice Optimized, Professional Grade

wp-content/uploads/2021/04/VO-series-2021.jpg

Authorized DD Audio Dealers Near You


Show results within of

The high output, voice optimized speakers are a hybrid of Pro Audio and Audiophile technologies. Shorting ring motors, long fiber curve sided cones, precise edge terminations and CnC motors with integrated Free Flow Cooling combine to give high fidelity at previously unattainable levels.

VO-MN6.5

Speaker Size (In): 6.5
Watts RMS: 60 - 300
Impedance: S4
VCD (In): 1.5
Frequency Response (Hz): 100 - 8k
Fs (Hz): 106
Qms: 3.89
Qes: 0.4
Qts: 0.362
Vas: 7.41
dBSPL: 95.5
Mounting Diameter (In): 5.66
Mounting Diameter (MM): 144
Mounting Depth (In): 2.83
Mounting Depth (MM): 72
Shipping Weight (Lbs): 5
Price (USD): 200

VO-MN8

Speaker Size (In): 8
Watts RMS: 60 - 300
Impedance: S4
VCD (In): 1.5
Frequency Response (Hz): 100 - 8k
Fs (Hz): 88
Qms: 4.264
Qes: 0.45
Qts: 0.407
Vas: 15.21
dBSPL: 95.5
Mounting Diameter (In): 7.25
Mounting Diameter (MM): 184.15
Mounting Depth (In): 3
Mounting Depth (MM): 77
Shipping Weight (Lbs): 5
Price (USD): 235

VO-M6.5a

Watts RMS: 60 - 300
Impedance: S4
VCD (In): 1.5
Frequency Response (Hz): 80 - 8k
Fs (Hz): 70
Qms: 2.275
Qes: 0.344
Qts: 0.299
Vas: 7.551
dBSPL: 91
Mounting Diameter (In): 5 3/5
Mounting Diameter (MM): 142.24
Mounting Depth (In): 2 3/10
Mounting Depth (MM): 58.42
Shipping Weight (Lbs): 5
Price (USD): 160

VO-M6x9a

Watts RMS: 60 - 300
Impedance: S4
VCD (In): 1.5
Frequency Response (Hz): 80 - 8k
Fs (Hz): 62
Qms: 2.465
Qes: 0.392
Qts: 0.338
Vas: 23.8
dBSPL: 95
Mounting Diameter (In): 6 x 9
Mounting Diameter (MM): 152.4 x 228.6
Mounting Depth (In): 3
Mounting Depth (MM): 76.2
Shipping Weight (Lbs): 6
Price (USD): 180

VO-M8a

Watts RMS: 60 - 300
Impedance: S4
VCD (In): 1.5
Frequency Response (Hz): 80 - 8k
Fs (Hz): 55
Qms: 2.273
Qes: 0.352
Qts: 0.305
Vas: 27.767
dBSPL: 93
Mounting Diameter (In): 7
Mounting Diameter (MM): 177.8
Mounting Depth (In): 3
Mounting Depth (MM): 76.2
Shipping Weight (Lbs): 5
Price (USD): 175

VO-XN6.5

Speaker Size (In): 6.5
Tweeter Speaker Size (In): 1
Watts RMS: 75
Watts Peak: 300
VCD (In): 1.5
Frequency Response (Hz): 100 - 20k
Fs (Hz): 100
Qms: 3.389
Qes: 0.4
Qts: 0.362
Vas: 7.41
dBSPL: 96
Tweeter dBSPL: 104
Mounting Diameter (In): 5.66
Mounting Diameter (MM): 144
Mounting Depth (In): 2.83
Mounting Depth (MM): 72
Price (USD): 275

VO-XN8

Speaker Size (In): 8
Tweeter Speaker Size (In): 1
Watts RMS: 75
Watts Peak: 300
Impedance: S4
VCD (In): 1.5
Frequency Response (Hz): 90 - 20k
Fs (Hz): 90
Qms: 4.264
Qes: 0.45
Qts: 0.407
Vas: 15.232
dBSPL: 96
Tweeter dBSPL: 104
Mounting Diameter (In): 7.25
Mounting Diameter (MM): 184.15
Mounting Depth (In): 3
Mounting Depth (MM): 77
Price (USD): 300

VO-W8b

Speaker Size (In): 8
Watts RMS: 150 - 450
Impedance: S4
VCD (In): 2.5
Frequency Response (Hz): 75 - 7k
Fs (Hz): 75
Qms: 5.398
Qes: 0.335
Qts: 0.316
Vas: 18.783
dBSPL: 96
Mounting Diameter (In): 7 1/4
Mounting Depth (In): 3 3/4
Price (USD): 140

VO-W10a

Watts RMS: 300 - 900
Impedance: S4
VCD (In): 3
Frequency Response (Hz): 60 - 6k
Fs (Hz): 60
Qms: 4.819
Qes: 0.375
Qts: 0.348
Vas: 54.802
dBSPL: 97
Mounting Diameter (In): 9 1/4
Mounting Depth (In): 4 3/8
Price (USD): 180

VO-B1a

Speaker Size (In): 1
Watts RMS: 50
Watts Peak: 100
Impedance: S4
Frequency Response (Hz): 3.5k - 20k
dBSPL: 104
Mounting Diameter (In): 2.3
Mounting Diameter (MM): 59
Mounting Depth (In): 1.5
Mounting Depth (MM): 38
Price (USD): 115

VO-B2a

Speaker Size (In): 1.5
Watts RMS: 50
Watts Peak: 150
Impedance: S4
VCD (In): 1.5
Frequency Response (Hz): 2.5k - 20k
dBSPL: 105
Mounting Diameter (In): 2.9
Mounting Diameter (MM): 74
Mounting Depth (In): 1.7
Mounting Depth (MM): 43
Price (USD): 170

VO-B3

Watts RMS: 50 - 100
Impedance: S4
VCD (MM): 25.4
Frequency Response (Hz): 3k - 20k
dBSPL: 106
Mounting Diameter (In): 1 11/16
Mounting Depth (In): 1 3/8
Shipping Weight (Lbs): 2
Price (USD): 95

VO-B4

Watts RMS: 50 - 150
Impedance: S4
VCD (MM): 38.6
Frequency Response (Hz): 2k - 20k
dBSPL: 108
Mounting Diameter (In): 1 15/16
Mounting Depth (In): 1 3/8
Shipping Weight (Lbs): 2
Price (USD): 105

VO-CT25

Speaker Size (In): 1
Watts RMS: 25 - 75
Watts Peak: 75
Impedance: S4
VCD (In): 1
Frequency Response (Hz): 2.5k - 20k
dBSPL: 107
Mounting Diameter (In): 1.4
Mounting Depth (In): 35
Price (USD): 135

VO-CT45

Watts RMS: 75 - 225
Impedance: 4
Frequency Response (Hz): 1.2k - 20k
dBSPL: 106
Mounting Diameter (In): 4 1/2
Mounting Depth (In): 2.08
Price (USD): 105

VO-CT5x5

Mounting Diameter (In): 3.25 x 3.25
Mounting Depth (In): 2.75
Price (USD): 10

VO-CTAL

Price (USD): 50

MC-8

Speaker Size (In): 8
Tweeter Speaker Size (MM): 25 (XN8, CT25) 45 (CT45)
Watts RMS: 250 - 500
Impedance: 4
Mounting Depth (In): 9.5
Shipping Weight (Lbs): 45
Price (USD): (1) 1,125, (2) 1,350, (3) 1,425
  • VO-XN6.5 VO-XN8
    Speaker Size (In): 6.5 8
    Speaker Size (MM): N/A N/A
    Tweeter Size (In): 1 1
    Tweeter Size (MM): N/A N/A
    Watts RMS: 75 75
    Watts Peak: 300 300
    Impedance: N/A S4
    Operating Voltage: N/A N/A
    Test Voltage: N/A N/A
    Input Channel(s): N/A N/A
    Output Channel(s): N/A N/A
    Cont Wattage @ 4 Ω: N/A N/A
    Cont Wattage @ 2 Ω: N/A N/A
    Cont Wattage @ 1 Ω: N/A N/A
    Dynamic Wattage: N/A N/A
    Max Current Draw (Amps): N/A N/A
    High-Level Input Sensitivity (Volts): N/A N/A
    RCA Output Voltage: N/A N/A
    RCA Input Impedance: N/A N/A
    High-Level Input Impedance: N/A N/A
    RCA Output Impedance: N/A N/A
    High-Level Input S/N: N/A N/A
    Damping Factor: N/A N/A
    THD: N/A N/A
    Channel Separation: N/A N/A
    Frequency Response (Hz): N/A N/A
    Frequency Response (Hz): N/A N/A
    Processing Speed: N/A N/A
    Bass Boost: N/A N/A
    VCD (In): 1.5 1.5
    VCD (MM): N/A N/A
    Piston Diameter (In): N/A N/A
    Piston Diameter (MM): N/A N/A
    Frequency Response (Hz): 100 - 20k 90 - 20k
    High-Pass Filter: N/A N/A
    Sub-Sonic Filter: N/A N/A
    Low-Pass Filter: N/A N/A
    ZVL Input: N/A N/A
    Pass Thru Output: N/A N/A
    Remote Control Option: N/A N/A
    Power Wire Gauge: N/A N/A
    Speaker Wire Gauge: N/A N/A
    Fs (Hz): 100 90
    Qms: 3.389 4.264
    Qes: 0.4 0.45
    Qts: 0.362 0.407
    Vas (Liters): 7.41 15.232
    dBSPL: 96 96
    Tweeter dBSPL: 104 104
    Xmech (In): N/A N/A
    Xmech (MM): N/A N/A
    Xmax (In): N/A N/A
    Xmax (MM): N/A N/A
    Frame OD (In): N/A N/A
    Frame OD (MM): N/A N/A
    Frame OD w/ Gasket (In): N/A N/A
    Frame OD w/ Gasket (MM): N/A N/A
    Mounting Diameter (In): 5.66 7.25
    Mounting Diameter (MM): 144 184.15
    Mounting Depth (In): 2.83 3
    Mounting Depth (MM): 72 77
    Motor Diameter (In): N/A N/A
    Motor Diameter (MM): N/A N/A
    Motor Depth (In): N/A N/A
    Motor Depth (MM): N/A N/A
    Magnet Weight (Oz): N/A N/A
    Magnet Weight (Gm): N/A N/A
    Woofer Displacement (CuFt): N/A N/A
    Woofer Displacement (Liters): N/A N/A
    Sealed Enclosure (CuFt): N/A N/A
    Sealed Enclosure (Liters): N/A N/A
    Ported Enclosure (CuFt): N/A N/A
    Ported Enclosure (Liters): N/A N/A
    Gauge: N/A N/A
    Wire Type: N/A N/A
    Spool Length (FT): N/A N/A
    Spool Length (Meters): N/A N/A
    Strand Count: N/A N/A
    Battery: N/A N/A
    Playtime: N/A N/A
    Rated Input Power: N/A N/A
    Cable: N/A N/A
    Plug: N/A N/A
    Port Length (In): N/A N/A
    Port Length (MM): N/A N/A
    Port Diameter (In): N/A N/A
    Port Diameter (MM): N/A N/A
    Dimensions (In): N/A N/A
    Dimensions (MM): N/A N/A
    Shipping Weight (Lbs): N/A N/A
    Shipping Weight (Kg): N/A N/A
    Price (USD): 275 per pair 300 per pair
  • VO-CT5x5 VO-CTAL
    Speaker Size (In): N/A N/A
    Speaker Size (MM): N/A N/A
    Tweeter Size (In): N/A N/A
    Tweeter Size (MM): N/A N/A
    Watts RMS: N/A N/A
    Watts Peak: N/A N/A
    Impedance: N/A N/A
    Operating Voltage: N/A N/A
    Test Voltage: N/A N/A
    Input Channel(s): N/A N/A
    Output Channel(s): N/A N/A
    Cont Wattage @ 4 Ω: N/A N/A
    Cont Wattage @ 2 Ω: N/A N/A
    Cont Wattage @ 1 Ω: N/A N/A
    Dynamic Wattage: N/A N/A
    Max Current Draw (Amps): N/A N/A
    High-Level Input Sensitivity (Volts): N/A N/A
    RCA Output Voltage: N/A N/A
    RCA Input Impedance: N/A N/A
    High-Level Input Impedance: N/A N/A
    RCA Output Impedance: N/A N/A
    High-Level Input S/N: N/A N/A
    Damping Factor: N/A N/A
    THD: N/A N/A
    Channel Separation: N/A N/A
    Frequency Response (Hz): N/A N/A
    Frequency Response (Hz): N/A N/A
    Processing Speed: N/A N/A
    Bass Boost: N/A N/A
    VCD (In): N/A N/A
    VCD (MM): N/A N/A
    Piston Diameter (In): N/A N/A
    Piston Diameter (MM): N/A N/A
    Frequency Response (Hz): N/A N/A
    High-Pass Filter: N/A N/A
    Sub-Sonic Filter: N/A N/A
    Low-Pass Filter: N/A N/A
    ZVL Input: N/A N/A
    Pass Thru Output: N/A N/A
    Remote Control Option: N/A N/A
    Power Wire Gauge: N/A N/A
    Speaker Wire Gauge: N/A N/A
    Fs (Hz): N/A N/A
    Qms: N/A N/A
    Qes: N/A N/A
    Qts: N/A N/A
    Vas (Liters): N/A N/A
    dBSPL: N/A N/A
    Tweeter dBSPL: N/A N/A
    Xmech (In): N/A N/A
    Xmech (MM): N/A N/A
    Xmax (In): N/A N/A
    Xmax (MM): N/A N/A
    Frame OD (In): N/A N/A
    Frame OD (MM): N/A N/A
    Frame OD w/ Gasket (In): N/A N/A
    Frame OD w/ Gasket (MM): N/A N/A
    Mounting Diameter (In): 3.25 x 3.25 N/A
    Mounting Diameter (MM): N/A N/A
    Mounting Depth (In): 2.75 N/A
    Mounting Depth (MM): N/A N/A
    Motor Diameter (In): N/A N/A
    Motor Diameter (MM): N/A N/A
    Motor Depth (In): N/A N/A
    Motor Depth (MM): N/A N/A
    Magnet Weight (Oz): N/A N/A
    Magnet Weight (Gm): N/A N/A
    Woofer Displacement (CuFt): N/A N/A
    Woofer Displacement (Liters): N/A N/A
    Sealed Enclosure (CuFt): N/A N/A
    Sealed Enclosure (Liters): N/A N/A
    Ported Enclosure (CuFt): N/A N/A
    Ported Enclosure (Liters): N/A N/A
    Gauge: N/A N/A
    Wire Type: N/A N/A
    Spool Length (FT): N/A N/A
    Spool Length (Meters): N/A N/A
    Strand Count: N/A N/A
    Battery: N/A N/A
    Playtime: N/A N/A
    Rated Input Power: N/A N/A
    Cable: N/A N/A
    Plug: N/A N/A
    Port Length (In): N/A N/A
    Port Length (MM): N/A N/A
    Port Diameter (In): N/A N/A
    Port Diameter (MM): N/A N/A
    Dimensions (In): N/A N/A
    Dimensions (MM): N/A N/A
    Shipping Weight (Lbs): N/A N/A
    Shipping Weight (Kg): N/A N/A
    Price (USD): 10 each 50 each
  • MC-8
    Speaker Size (In): 8
    Speaker Size (MM): N/A
    Tweeter Size (In): N/A
    Tweeter Size (MM): 25 (XN8, CT25) 45 (CT45)
    Watts RMS: 250 - 500
    Watts Peak: N/A
    Impedance: 4
    Operating Voltage: N/A
