SS5.500

AB 4ch + D Mono

wp-content/uploads/2025/02/SS5.500-5ch-amplifier-feature.jpg

Search Authorized DD AUDIO Dealers Near You

Five channel systems can be easily configured and tuned with the new SS5.500. This multichannel amp features an AB Class 4 channel paired to an efficient D Class subwoofer mono channel giving your system the best of both circuit designs.

The AB Class amp features Elna capacitors, precision resistors and high specification transistors delivering a precise, transparent response to your mid and high frequency drivers. AB Class amps are renowned for their overall warmth, clarity and control. Your soundstage will be vibrant and spatial, making your drive-time something to look forward to every day.

The low frequency section is a high speed class D featuring International Rectifier components coupled to a high current toroidal power supply, making the most efficient power from your vehicle’s stock electrical system. Powerful, deep and impactful bass will fill your space without having to modify your stock electrical system.

High fidelity audio is within the realm of every car with the SS5.500.

Features

  • 12dB/Oct High Pass/Low Pass X-Overs
  • Dual Toroidal Power Supply
  • Heavyweight DD Aluminum Chassis
  • Set Screw Power and Speaker Terminals
  • Remote Gain Control

SS5.500

Operating Voltage: 9 - 16
Test Voltage: 14.4
Input Channel(s): 6
Output Channel(s): 5
Continuous Wattage @4ohm: 80 x 4
Continuous Wattage @2ohm: 120 x 4
Continuous Wattage @1ohm: 500 x 1
Max Current Draw (Amps): 100
RCA Input Voltage Sensitivity: 8 - 0.2
High-Level Input Voltage Sensitivity: 20 - 1.1
RCA Input S/N: > 95
Damping Factor: > 100
THD: < 1.0%
Frequency Response (Hz): 20 - 20k
High Pass Filter: 20 - 5k
Sub-Sonic Filter: 10 - 50
Low-Pass Filter: 50 - 5k
Remote Control: Remote Included in Box
Power Wire Gauge: 4
Speaker Wire Gauge: 12
Dimensions (Inches): 13.5 x 7.3 x 2.4
Dimensions (MM): 340 x 185 x 60
Shipping Weight (Lbs): 5
Price (USD): 289 each

For the SS Series the main design focus was to pack as much full-range stereo output capability as possible into as compact of a chassis as possible. We utilized discrete circuit class D technology for ultra low distortion levels that rival class AB designs. The resulting amp is capable of driving multiple driver mid-range and tweeter arrays while consuming less current, taking up less space and delivering more power.
